Servicing the Motherboard (FRU)
162 Oracle Server X6-2 Service Manual • June 2016
Servicing the Motherboard (FRU)
Follow these procedures to remove and install the motherboard.
Caution - The motherboard should be serviced only by an Oracle qualified service technician.
Caution - Ensure that all power is removed from the server before removing or installing the
motherboard. You must disconnect the power cables before performing these procedures.
Caution - These procedures require that you handle components that are sensitive to
electrostatic discharge. This sensitivity can cause the components to fail. To avoid
damage, ensure that you follow antistatic practices as described in “Take Antistatic
Measures” on page 59.
■
“Remove the Motherboard” on page 162
■
“Install the Motherboard” on page 169
Related Information
■
“Remove the Server From the Rack” on page 58
■
“Take Antistatic Measures” on page 59
■
“Remove the Server Top Cover” on page 60
Remove the Motherboard
Caution - The motherboard should be serviced only by an Oracle qualified service technician.
Caution - Use the Oracle ILOM backup utility prior to removing the motherboard. This utility
backs up the Oracle ILOM configuration of the service processor. For more information, see the
Oracle ILOM 3.2 Documentation Library at http://www.oracle.com/goto/ilom/docs.
1.
Prepare the server for service.
a.
Power off the server and disconnect the power cords from the power
supplies.
See “Powering Down the Server” on page 51.
