Install the PCIe Riser Into PCIe Slots 3 and 4
Servicing CRUs That Require Server Power-Off 105
9.
Place the riser on an antistatic mat.
Related Information
■
“Install the PCIe Riser Into PCIe Slots 3 and 4” on page 105
Install the PCIe Riser Into PCIe Slots 3 and 4
Note - The PCIe riser in slots 3 and 4 is different than the PCIe risers in slots 1 and 2. Do not
attempt to install a PCIe riser from slot 1 or 2 into PCIe slots 3 and 4 and vice versa.
1.
Retrieve the PCIe riser and any PCIe cards attached to it.
2.
Reconnect the SAS cables to the internal host bus adapter card.
