Oracle X6-2 - BIOS Advanced Menu BMC Network Configuration Options

BIOS Advanced Menu Selections
238 Oracle Server X6-2 Service Manual • June 2016
Setup Options Options Defaults Description
disable, the IPv4 Boot
Option will not be created.
Ipv6 PXE Support Disabled/Enabled Disabled Enable or disable IPv6
PXE Boot support. If
disable, the IPv6 Boot
Option will not be created.
BIOS Advanced Menu BMC Network Configuration
Options
The following table lists the BIOS Advanced Menu BMC Network Configuration options.
TABLE 35
BIOS Advanced Menu BMC Network Configuration Options
Setup Options Options Defaults Description
Current Active
Management Port (R/O)
NA NETMGT The currently active
management port.
Refresh NA NA Refresh current BMC
LAN information with the
latest information from the
service processor.
Active Mgmt Port NET MGT/NET0/NET1/
NET2/NET3
NET MGT Use to change the
currently active network
management port.
Commit NA NA Commit the current BMC
network LAN information.
IPv4 Configuration NA NA Current configuration
of the IPv4 settings is
displayed.
Channel Number (R/O) 1 Current channel number is
displayed.
Current IPv4 IP
Assignment in BMC (R/O)
Static/Dynamic Static Set the IPV4 IP
assignment to Static or
Dynamic. This setting
determines whether
the service processor is
assigned a static IPv4
address or assigned a
dynamic IPv4 address
using Dynamic Host
Control Protocol (DHCP).
Current IPv4 address in
BMC (R/O)
NA NA Displays the current IPv4
address in the BMC.
Current IPv4 MAC
Address in BMC (R/O)
NA NA If IPv4 Assignment is
set to Static, set the IPv4
address for the service
processor.
