Install the Battery
Servicing CRUs That Require Server Power-Off 117
c.
Attach an antistatic wrist strap to your wrist and then to a metal area on the
chassis.
See “Take Antistatic Measures” on page 59.
d.
Remove the server top cover.
See “Remove the Server Top Cover” on page 60.
2.
If there is a PCIe card installed in the PCIe riser slot 2, remove the riser and card
to gain access to the battery.
See “Remove a PCIe Riser From PCIe Slot 1 or 2” on page 99
3.
To dislodge the battery from the retainer, place your finger under the side of the
battery nearest the rear of the server [1] and gently lift the battery up and out of
the retainer [2].
FIGURE  23
Removing the Battery
Install the Battery
1.
Unpack the replacement battery.
2.
Press the new battery into the battery retainer with the positive side (+) facing up
(see Figure 23[1]).
3.
If there was a PCIe card installed in the PCIe riser slot 2, reinstall it.
