Remove the Front Indicator Module
Servicing FRUs 159
Caution - Ensure that all power is removed from the server before removing or installing a front
indicator module. You must disconnect the power cables from the server before performing
these procedures.
Follow these procedures to remove and install the front indicator module (FIM).
■
“Remove the Front Indicator Module” on page 159
■
“Install the Front Indicator Module ” on page 161
Related Information
■
“Disconnect Cables From the Server” on page 56
■
“Remove the Server From the Rack” on page 58
■
“Take Antistatic Measures” on page 59
■
“Open the Server Fan Door” on page 59
Remove the Front Indicator Module
Caution - The front indicator module should be removed only by authorized Oracle Services
personnel.
1.
Prepare the server for service.
a.
Power off the server and disconnect the power cords from the power
supplies.
See “Powering Down the Server” on page 51.
b.
Extend the server to the maintenance position.
See “Extend the Server to the Maintenance Position” on page 56.
c.
Attach an antistatic wrist strap to your wrist, and then to a metal area on the
chassis.
See “Take Antistatic Measures” on page 59.
2.
To remove the top cover from the storage drive cage, do the following [1]:
a.
Remove the six Phillips screws from the top of the storage drive cage.
There are three Phillips screws on each side of the storage drive cage.
b.
Open the server fan door.
