Identifying the Server Ports 195
Identifying the Server Ports
This section describes the pinouts of the server connectors.
Description Links
Learn about the Gigabit Ethernet ports. “Gigabit Ethernet Ports” on page 195
Learn about the network management port. “Network Management Port” on page 196
Learn about the serial management port. “Serial Management Port” on page 197
Learn about the video connector. “Video Connector” on page 198
Learn about USB ports. “USB Ports” on page 199
Gigabit Ethernet Ports
The server has four auto-negotiating 100/1000/10,000BASE-T gigabit Ethernet (GbE) system
domain ports. All four Ethernet ports use a standard RJ-45 connector. The transfer rates are
shown in the following table.
TABLE 16
Ethernet Port Transfer Rates
Connection Type IEEE Terminology Transfer Rate
Fast Ethernet 100BASE-TX 100 Mbps
Gigabit Ethernet 1000BASE-T 1,000 Mbps
10 Gigabit Ethernet 10GBASE-T 10,000 Mbps
The following figure and table describe the 10-GbE port pin signals.
Note - Ethernet ports NET 2 and NET 3 are nonfunctional in single-processor systems.
