Removing the Power, FIM, Disk Backplane Data, and DVD Cables
182 Oracle Server X6-2 Service Manual • June 2016
■
“Take Antistatic Measures” on page 59
■
“Remove the Server Top Cover” on page 60
Removing the Power, FIM, Disk Backplane Data,
and DVD Cables
Caution - The Power, front indicator module, disk backplane data, and DVD cables should be
removed only by authorized Oracle Services personnel.
1.
Prepare the server for service.
a.
Power off the server and disconnect the power cords from the power
supplies.
See “Powering Down the Server” on page 51.
b.
Extend the server to the maintenance position.
See “Extend the Server to the Maintenance Position” on page 56.
c.
Attach an antistatic wrist strap to your wrist, and then to a metal area on the
chassis.
See “Take Antistatic Measures” on page 59.
d.
Remove the server top cover.
See “Remove the Server Top Cover” on page 60.
2.
Remove all of the server fan modules.
See “Remove a Fan Module” on page 76.
3.
To remove the disk backplane power cable, perform these steps:
a.
To disconnect the disk backplane power cable from the motherboard,
press the release latches on the sides of the cable connector and pull the
connector out. [1].
b.
To disconnect the disk backplane power cable from the disk backplane,
press the release latches on the side of the cable connector and pull the
connector out. [2].
