Servicing the Internal HBA SAS Cable assembly
Servicing FRUs 173
Servicing the Internal HBA SAS Cable assembly
Caution - The internal HBA SAS cable assembly should be serviced only by authorized Oracle
Services personnel.
Caution - These procedures require that you handle components that are sensitive to
electrostatic discharge. This sensitivity can cause the components to fail. To avoid
damage, ensure that you follow antistatic practices as described in “Take Antistatic
Measures” on page 59.
Caution - The system supplies power to the cables even when the server is powered off.
To avoid personal injury or damage to the server, you must disconnect power cords before
servicing the cables.
Tfhis section covers the following procedures:
■
“Remove the Internal HBA SAS Cable Assembly” on page 173
■
“Install the Internal HBA SAS Cable Assembly” on page 176
Related Information
■
“Extend the Server to the Maintenance Position” on page 56
■
“Take Antistatic Measures” on page 59
■
“Remove the Server Top Cover” on page 60
Remove the Internal HBA SAS Cable Assembly
Caution - The internal HBA SAS cable assembly should be removed only by an Oracle
qualified service technician.
1.
Prepare the server for service.
a.
Power off the server and disconnect the power cords from the power
supplies.
See “Powering Down the Server” on page 51.
b.
Extend the server to the maintenance position.
See “Extend the Server to the Maintenance Position” on page 56.
