Monitoring System Components
Monitoring Components and Identifying SNMP Messages 259
Component Name (Oracle
ILOM CLI Targets)
IPMI Type Description Values (if applicable)
/SYS/MB/P[0-x]/V_DIMM Static sensor CPU DIMM bank
operating voltage
1.2V
Related Information
■
“System Chassis Components” on page 253
■
“Cooling Unit Components” on page 255
■
“Disk Backplane Components” on page 255
■
“Memory Device Components” on page 256
■
“Power Unit Components” on page 257
■
“System Board Components” on page 259
■
“System Firmware Components” on page 261
■
“Hard Disk Drive Components” on page 262
System Board Components
The following table lists the system board components.
Component Name (Oracle ILOM CLI
Targets)
IPMI Type Description Values (if
applicable)
/SYS/MB FRU General host system board FRU
/SYS/MB/CPLD FRU Mainboard CPLD/FPGA firmware
version
/SYS/MB/NET[0-3] FRU Host Ethernet FRU
/SYS/MB/RISER[1-3]/PRSNT Discrete
sensor
PCIe riser inserted into PCIe slot 01h-
ENTITY_ABSENT
02h-
ENTITY_PRESENT
/SYS/MB/RISER1/PCIE1/PRSNT Discrete
sensor
Option card inserted into PCIe riser 1 01h-
ENTITY_ABSENT
02h-
ENTITY_PRESENT
/SYS/MB/RISER2/PCIE2/PRSNT Discrete
sensor
Option card inserted into PCIe riser 2 01h-
ENTITY_ABSENT
02h-
ENTITY_PRESENT
/SYS/MB/RISER3/PCIE3/PRSNT Discrete
sensor
Option card inserted into slot 3 of
PCIe riser 3
01h-
ENTITY_ABSENT
