Oracle X6-2 - Server Fan Status Indicators; Storage Drive Status Indicators

Troubleshoot Hardware Faults Using the Oracle ILOM Web Interface
30 Oracle Server X6-2 Service Manual • June 2016
Status
Indicator Name
Icon Colors State and Meaning
Top Fan TOP Amber Indicates that one or more of the internal fan modules
have failed.
■ OFF – Indicates steady state; no service is
required.
■ STEADY ON – Indicates service required.
Rear Power
Supply Fault
REAR Amber Indicates that one of the server power supplies has
failed.
■ OFF – Indicates steady state; no service is
required.
■ STEADY ON – Indicates service required;
service the power supply.
System Over
Temperature
Warning
Amber Indicates a warning for an over temperature
condition.
■ OFF – Normal operation; no service is required.
■ STEADY ON – The system is experiencing an
overtemperature warning condition.
Note - This is a warning indication, not a fatal
overtemperature. Failure to correct this might
result in the system overheating and shutting down
unexpectedly.
Server Fan Status Indicators
Each fan module has one status indicator (LED). The LEDs are located on the chassis mid-
wall adjacent to and aligned with the fan modules and are visible when the top cover fan door is
open.
TABLE 2
Server Fan Status Indicators
Status
Indicator
Name
Icon Color State and Meaning
Fan Status Amber ■ Off – The fan module is correctly installed and operating within specification.
■ Amber – The fan module is faulty. The front TOP FAN LED and the front and rear
panel Service Required LEDs are also lit if the system detects a fan module fault.
Storage Drive Status Indicators
There are three status indicators (LEDs) on each drive.
