Oracle X6-2 - Remove the Internal HBA Card from Pcie Slot 4

Remove the Internal HBA Card From PCIe Slot 4
Servicing FRUs 141
Caution - These procedures require that you handle components that are sensitive to
electrostatic discharge. This sensitivity can cause the components to fail. To avoid
damage, ensure that you follow antistatic practices as described in “Take Antistatic
Measures” on page 59.
Caution - Ensure that all power is removed from the server before removing or installing the
internal HBA. You must disconnect the power cables from the server before performing these
procedures.
■
“Remove the Internal HBA Card From PCIe Slot 4” on page 141
■
“Install the Internal HBA Card in PCIe Slot 4” on page 145
Related Information
■
“Disconnect Cables From the Server” on page 56
■
“Take Antistatic Measures” on page 59
■
“Extend the Server to the Maintenance Position” on page 56
■
“Open the Server Fan Door” on page 59
Remove the Internal HBA Card From PCIe Slot 4
1.
Prepare the server for service.
a.
Power off the server and disconnect the power cords from the power
supplies.
See “Powering Down the Server” on page 51.
b.
Extend the server to the maintenance position.
See “Extend the Server to the Maintenance Position” on page 56.
c.
Attach an antistatic wrist strap to your wrist, and then to a metal area on the
chassis.
See “Take Antistatic Measures” on page 59.
d.
Open the server fan door to gain access to the disk backplanes.
See “Open the Server Fan Door” on page 59
e.
Remove fan module FM0 (the left most fan viewing the server from the
front).
