Troubleshoot Hardware Faults Using the Oracle ILOM Web Interface
Troubleshooting and Diagnostics 31
TABLE 3
Server Front Storage Drive Indicators
Status
Indicator Name
Icon Color State and Meaning
OK/Activity Green ■ OFF – Power is off or the installed drive is not recognized by the system.
■ STEADY ON – The drive is engaged and is receiving power.
■ Random BLINK – There is disk activity. The indicator blinks on and off to indicate
activity.
Service
Required
Amber ■ OFF – The storage drive is operating normally.
■ STEADY ON – The system has detected a fault with the storage drive.
OK to Remove Blue ■ STEADY ON – The storage drive can be removed safely during a hot-plug operation.
■ OFF – The storage drive has not been prepared for removal.
Power Supply Status Indicators
There are two status indicators (LEDs) on each power supply. These indicators are visible from
the rear of the server.
TABLE 4
Server Power Supply Indicators
Status
Indicator
Name
Icon Color State and Meaning
AC OK/DC
OK
Green ■ OFF – No AC power is present.
■ SLOW BLINK – Normal operation. Input power is within
specification. DC output voltage is not enabled.
■ STEADY ON – Normal operation. Input AC power and DC
output voltage are within specification.
Service
Required
Amber ■ OFF – Normal operation. No service action is required.
■ STEADY ON – The power supply (PS) has detected a PS fan
failure, PS overtemperature, PS over current, or PS over or under
voltage.
Network Management Port Status Indicators
The server has one 10/100/1000 BASE-T Ethernet management domain interface, labeled NET
MGT. There are two status indicators (LEDs) on this port. These indicators are visible from the
rear of the server.
TABLE 5
Network Management Port Status Indicators
Status
Indicator
Name
Location Color State and Meaning
Activity Top right Green ■ ON – Link up.
■ OFF – No link or down link.
