Install a Power Supply
Servicing CRUs That Do Not Require Server Power-Off 83
Figure Legend
1
Power Supply 0 (PS0)
2
Power Supply 1 (PS1)
6.
Pull the power supply out of the chassis [2].
Caution - Whenever you remove a power supply, you should replace it with another power
supply; otherwise, the server might overheat due to improper airflow.
7.
Continue to “Install a Power Supply” on page 83.
Related Information
■
“Server Back Panel View” on page 16
■
“Power Supply Status Indicators” on page 81
■
“Install a Power Supply” on page 83
Install a Power Supply
Caution - Always replace a faulty power supply with a power supply of the same type (model).
1.
Remove the replacement power supply from its packaging and place it on an
antistatic mat.
2.
Align the replacement power supply with the empty power supply slot [1].
3.
Slide the power supply into the bay until it is fully seated [2].
