Monitoring System Components
262 Oracle Server X6-2 Service Manual • June 2016
Hard Disk Drive Components
The following table lists the hard disk drive (HDD) components.
Component Name (Oracle ILOM
CLI Targets)
IPMI Type Description Values (if applicable)
/SYS/DBP/HDD[0-x] FRU Hard disk drive FRU From host
/SYS/DBP/HDD[0-x]/PRSNT Discrete
sensor
Hard disk drive presence 01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
/SYS/DBP/HDD[0-x]/STATE Discrete
sensor
Writable multistate, slot/
connector sensor type, per
IPMI
02h-DRIVE_FAULT
04h-
PREDICTIVE_FAILURE
08h-HOT_SPARE
/SYS/DBP/HDD[0-x]/SERVICE Indicator Hard disk drive Service
Required LED
Color: Amber
Location: Hard disk drive
Off: Normal
On: Hard disk drive was
diagnosed as faulty.
/SYS/DBP/HDD[0-x]/OK2RM Indicator Hard disk drive OK to
Remove LED
Color: Blue
Location: Hard disk drive
Off: Normal
On: OK to remove
/SYS/DBP/NVME[0-x] FRU NVMe storage drive FRU
/SYS/DBP/NVME[0-x]/PRSNT Discrete
sensor
NVMe storage drive 01h-ENTITY_PRESENT
02h-ENTITY_ABSENT
Related Information
■
“System Chassis Components” on page 253
■
“Cooling Unit Components” on page 255
■
“Disk Backplane Components” on page 255
■
“Memory Device Components” on page 256
■
“Power Unit Components” on page 257
■
“Processor Components” on page 258
■
“System Board Components” on page 259
■
“System Firmware Components” on page 261
