Remove an Internal USB Flash Drive
114 Oracle Server X6-2 Service Manual • June 2016
■
“Remove the Server Top Cover” on page 60
Remove an Internal USB Flash Drive
The server can be equipped with up to two internal USB flash drives.
1.
Prepare the server for service.
a.
Power off the server and disconnect the power cords from the power
supplies.
See “Powering Down the Server” on page 51
b.
Extend the server to the maintenance position.
See “Extend the Server to the Maintenance Position” on page 56.
c.
Attach an antistatic wrist strap to your wrist and then to a metal area on the
chassis.
See “Take Antistatic Measures” on page 59.
d.
Remove the server top cover.
See “Remove the Server Top Cover” on page 60.
2.
Grasp the USB flash drive and pull it out of the internal USB port .
