Remove the Oracle PCIe NVMe Switch Card From PCIe Slot 1
138 Oracle Server X6-2 Service Manual • June 2016
Remove the Oracle PCIe NVMe Switch Card From
PCIe Slot 1
1.
Prepare the server for service.
a.
Power off the server and disconnect the power cords from the power
supplies.
See “Powering Down the Server” on page 51.
b.
Extend the server to the maintenance position.
See “Extend the Server to the Maintenance Position” on page 56.
c.
Attach an antistatic wrist strap to your wrist, and then to a metal area on the
chassis.
See “Take Antistatic Measures” on page 59.
d.
Open the server fan door to gain access to the disk backplanes.
See “Open the Server Fan Door” on page 59
e.
Remove fan module FM0 (the left most fan viewing the server from the
front).
See “Remove a Fan Module” on page 76.
2.
Remove the PCIe riser from slot 1.
For instructions, see “Remove a PCIe Riser From PCIe Slot 1 or 2” on page 99.
