Oracle X6-2 - Cooling Unit Components; Disk Backplane Components

Monitoring System Components
Monitoring Components and Identifying SNMP Messages 255
■
“System Firmware Components” on page 261
■
“Hard Disk Drive Components” on page 262
Cooling Unit Components
The system has 3.5-inch fan modules with two fans in each module. The following table lists
the system cooling unit components.
Component Name (Oracle
ILOM CLI Targets)
IPMI Type Description Values (if applicable)
/SYS/MB/FM[0-3] FRU Fan module FRU
/SYS/MB/FM[0-3]/F[0-x] FRU Individual fan
/SYS/MB/FM[0-3]/PRSNT Discrete
sensor
Fan module is present. 01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
/SYS/MB/FM[0-3]/F[0-x]/
TACH
Threshold
sensor
Fan module fan speed RPM
/SYS/MB/FM[0-
3]/SERVICE
Indicator Fan Service Required LED Color: Amber
Location: Motherboard
Off: Normal
On: Fan module was diagnosed as
faulty.
Related Information
■
“System Chassis Components” on page 253
■
“Disk Backplane Components” on page 255
■
“Memory Device Components” on page 256
■
“Power Unit Components” on page 257
■
“Processor Components” on page 258
■
“System Board Components” on page 259
■
“System Firmware Components” on page 261
■
“Hard Disk Drive Components” on page 262
Disk Backplane Components
The following table lists the disk backplane (DBP) components.
