Monitoring System Components
254 Oracle Server X6-2 Service Manual • June 2016
Component Name
(Oracle ILOM CLI
Targets)
IPMI
Type
Description Values (if applicable)
Standby blink: Standby power is on, but the
chassis power is off and the Oracle ILOM SP is
running.
Slow blink: Startup sequence has been initiated
on the host.
Steady on: Server is powered on and the host is
booting OS or the host is running the OS.
/SYS/SERVICE Indicator Service Required LED Color: Amber
Location: Front panel
Off: Normal
On: Server requires service.
/SYS/LOCATE Indicator Locator LED Color: White
Location: Front and rear panels
Off: Normal
Fast blink: Locate function is activated; self-
extinguishes after 30 minutes.
/SYS/HOST_ERR Discrete
sensor
Host asserted error sensor 01h-Deasserted
02h-Asserted
/SYS/PS_FAULT Indicator Rear Power Supply Fault
LED
Color: Amber
Location: Mainboard
Off: Normal
On: General power supply fault
/SYS/FAN_FAULT Indicator Top Fan Fault LED Color: Amber
Location: Mainboard
Off: Normal
On: General fan fault
Related Information
■
“Cooling Unit Components” on page 255
■
“Disk Backplane Components” on page 255
■
“Memory Device Components” on page 256
■
“Power Unit Components” on page 257
■
“Processor Components” on page 258
■
“System Board Components” on page 259
