Monitoring System Components
260 Oracle Server X6-2 Service Manual • June 2016
Component Name (Oracle ILOM CLI
Targets)
IPMI Type Description Values (if
applicable)
02h-
ENTITY_PRESENT
/SYS/MB/RISER3/PCIE4/PRSNT Discrete
sensor
Internal HBA card inserted into slot 4
of PCIe riser 3
01h-
ENTITY_ABSENT
02h-
ENTITY_PRESENT
/SYS/MB/RISER1/PCIE1/PCIESW FRU Optional Oracle PCIe NVMe switch
card, dedicated slot
01h-
ENTITY_ABSENT
02h-
ENTITY_PRESENT
/SYS/MB/RISER1/PCIE1/PCIESW/
PRSNT
FRU Optional Oracle PCIe NVMe switch
card inserted into slot 1 of PCIe riser
1, dedicated slot
01h-
ENTITY_ABSENT
02h-
ENTITY_PRESENT
/SYS/MB/T_OUT_SLOT[1-3] Threshold
sensor
Cooling zone chassis exhaust
temperature, located behind the
specified PCIe slots.
■ Slot 1 – PCIe slot 1
■ Slot 2 – PCIe slot 2
■ Slot 3 – PCIe slot 3
Degrees Celsius
/SYS/MB/T_IN_SLOT[1-3] Threshold
sensor
Cooling zone chassis inlet
temperature, located in front of the
specified PCIe slots.
■ Slot 1 – PCIe slot 1
■ Slot 2 – PCIe slot 2
■ Slot 3 – PCIe slot 3
Degrees Celsius
/SYS/MB/T_CORE_NET01 Threshold
sensor
Gigabit Ethernet controller die
temperature
CPU 0, NET 0+1
Degrees Celsius
/SYS/MB/T_CORE_NET23 Threshold
sensor
Gigabit Ethernet controller die
temperature
CPU 1, NET 2+3
Degrees Celsius
/SYS/MB/T_IN_SLOT[1-3] Threshold
sensor
PCIE slot input temperature Degrees Celsius
/SYS/MB/T_OUT_SLOT[1-3] Threshold
sensor
PCIE slot output temperature Degrees Celsius
/SYS/MB/T_IN_PS Threshold
sensor
Power supply unit (PSU) inlet
temperature, located directly in front
of the PSU 0 air inlet.
Degrees Celsius
/SYS/SP FRU Service processor FRU
/SYS/SP/OK Indicator SP OK LED Color: Green
Location: Front
panel
On: SP is operating.
