BIOS Advanced Menu Selections
BIOS Setup Utility Menu Options 239
Setup Options Options Defaults Description
Example: 172.31.255.255
Current IPv4 Subnet Mask
in BMC (R/O)
NA NA If the IPv4 Assignment is
set to Static, set the IPv4
subnet mask.
Example: 255.255.255.0
Current IPv4 Default
Gateway in BMC
NA NA If the IPv4 Assignment is
set to Static, set the IPv4
default gateway
Example: 172.31.255.255
Refresh Refresh the current BMC
LAN information.
IPv4 IP Assignment Static/Dynamic Static Current IPv4 assignment.
IPv4 Address NA NA If set, current IPv4 address
is displayed.
IPv4 Subnet Mask NA NA If set, current IPv4 Subnet
Mask is displayed.
IPv4 Default Gateway NA NA If set, current Default IPv4
Gateway is displayed.
Commit Commit the current BMC
LAN information.
IPv6 Configuration Current configuration
of the IPv6 settings is
displayed.
IPv6 addresses are written
with hexadecimal digits
and colon separators. For
example: 2001:0db0:000:
82a1:0000:0000:1234:
abcd.
IPv6 addresses are
composed of two parts: a
64-bit subnet prefix and
a 64-bit host interface
ID. To shorten the IPv6
address, you can (1) omit
all leading zeros, and (2)
replace one consecutive
group of zeros with a
double colon (::). For
example: 2001:db0:0:
82a1::1234:abcd.
Channel Number (R/O) 1 Current channel number is
displayed.
Current IPv6 State (R/O) Enabled/Disabled Enabled Current IPv6 state is
displayed.
