Remove a Processor
Servicing FRUs 129
d.
Grasp the tool by the sides and remove it from the server [4].
e.
Turn the tool upside down and verify that it contains the processor [5].
f.
While holding the processor tool up side down, press the center button on
the tool to release the processor [5].
g.
Carefully grasp the processor by the front and back edges, lift it out of the
tool and place it with the circuit side down (the installed orientation) into an
antistatic container [6].
h.
Carefully clean the thermal grease off the top of the processor.
Caution - The following figure shows the green color-coded processor removal and
replacement tool. If you are removing a processor with 12 or more cores, you must use the
pink color-coded processor removal and replacement tool; otherwise, damage might result to
the processor or the processor socket. For information on how to select the correct processor
removal and replacement tool, see “Selecting the Correct Processor Removal and Replacement
Tool” on page 120.
