Install a Processor
132 Oracle Server X6-2 Service Manual • June 2016
c.
Lower the processor into the tool and press the tool release lever to release
the center button and engage the processor [3].
An audible click indicates that the processor is locked in place.
d.
Properly position the tool over the processor socket and lower it into place
[4].
To properly position the tool in the processor socket, rotate the tool until the green triangle
on the side of the tool is facing the front of the server and it is over the left side of the
processor socket (when viewing the server from the front) and lower the tool into the
processor socket.
e.
Press the center button in the tool down to release the processor so that it is
placed in the socket [5].
f.
Remove the processor removal and replacement tool [6].
Caution - The following figure shows the green color-coded processor removal and
replacement tool. If you are installing a processor with 12 or more cores, you must use the
pink color-coded processor removal and replacement tool; otherwise, damage might result to
the processor or the processor socket. For information on how to select the correct processor
removal and replacement tool, see “Selecting the Correct Processor Removal and Replacement
Tool” on page 120.
