Removing the NVMe Cables
Servicing FRUs 179
3.
To disconnect the switch card cables from the disk backplane, press the latches
on the cable connectors and pull the connectors out [1].
4.
Remove the PCIe riser that contains the switch card from PCIe slot 1.
See “Remove a PCIe Riser From PCIe Slot 1 or 2” on page 99.
5.
Disconnect the cables from the switch card. [2]
6.
Carefully pull the switch card cables through chassis mid-wall and remove them
from the server.
Related Information
■
“Install the NVMe Cables” on page 180
