007 Paper Transport Unit
Detection Sensor
Unit is connected. 0
Paper Transport Unit Door
Sensor
Door is open. 0
Paper Transport Unit
Sensor 4
Paper is detected. 0
Paper Transport Unit
Sensor 3
Paper is detected. 0
Paper Transport Unit
Sensor 2
Paper is detected. 0
ADU Sensor 4 Paper is detected. 0
ADU Sensor 3 Paper is detected. 0
ADU Sensor 2 Paper is detected. 0
008 Bottom Sensor
(Sheet Bypass)
Home position is
detected.
1
Front / Right Cover Open
Sensor 2
See Remarks. * Front / Right Cover is
closed.
Signal 1 = 0
Signal 2 = 0
Right Cover is open.
Signal 1 = 1
Signal 2 = 1
Front / Right Cover Open
Sensor 1
See Remarks. *
Developer Unit Detecting
Sensor
Unit is connected. 1
009 JAM Access Cover Open
Detection Sensor
(4th Paper Feed Module)
Cover is open. 0
Paper Tray Detection
Sensor
(4th Paper Tray)
Paper Tray is not
connected.
0
Upper Limit Sensor
(4th Paper Tray)
Upper Limit is detected. 1
Paper Feed Module
Detection Sensor
(4th Paper Feed Module)
Unit is connected. 0
Feed Motor Lock Signal
(3rd Paper Tray)
Normal. 0
Paper Feed Module
Detection Sensor 2
(3rd Paper Feed Module)
See Remarks. * Unit is connected.
Signal 1 = 1
Signal 2 = 0
A different signal
pattern, indicates that
the unit is not
connected, or CST 3
PCB is defective.
Paper Feed Module
Detection Sensor 1
(3rd Paper Feed Module)
See Remarks. *
F4 Mode (Input Check)
No. Function Condition
Message Display
Remarks
76543210
