010 Registration Sensor
(3rd Paper Tray)
Paper is detected. 0
JAM Access Cover Open
Detection Sensor
(3rd Paper Tray)
Cover is open. 0
Paper Tray Detection
Sensor
(3rd Paper Tray)
Paper Tray is
connected.
1
Upper Limit Sensor
(3rd Paper Tray)
Upper Limit is detected. 1
NP Sensor
(3rd Paper Tray)
Paper is not detected. 0
Registration Sensor
(4th Paper Tray)
Paper is detected. 0
NP Sensor
(4th Paper Tray)
Paper is not detected. 0
011 Book Fan Lock Signal Normal. 0
013 Paper Entrance Sensor Paper is detected. 1 1-Bin Finisher
(FS300).
Paper Exit Sensor Paper is detected. 1
Home Position Sensor Home position is
detected.
1
Paper Level Sensor
Paper Hold Sensor
Paper Hold Lever is
outside.
00
Paper level is
base line.
01
Paper Hold Lever is
inside.
10
Paper level is
upper limit.
11
Paper Upper Limit Sensor Paper Upper Limit is
detected.
1
Paper Tray Full Sensor Paper Full is detected. 1
Front Stapler Home
Position Sensor
Home position is
detected.
1
014 Stapler Cartridge Sensor Stapler Cartridge is
detected.
1
Staple Sensor Staple is empty. 0
Stapler Unit Sensor Stapler Unit is detected. 1
Stapler Cover Switch Cover is open. 0
Top Cover Sensor Cover is open. 0
Joint Detect Sensor Finisher Unit is not
detected.
0
F4 Mode (Input Check)
No. Function Condition
Message Display
Remarks
76543210
