LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
OEM PCB/NIBP Module Cable (W27) Replacement
Section Menu Section Contents Back Index
349
8
Removing the OEM PCB/NIBP Module Cable (W27)
Refer to Figure 8.117 on p. 348.
To remove the OEM PCB/NIBP module cable (3012181-00) from the rear case:
1. Disassemble the case as described in Disassembling the Case (p. 181).
2. Remove the system/therapy PCB assembly as described in System (A01)/Therapy (A04) PCB Assembly Replacement (p. 232).
3. Remove the OEM PCB (A06) as described in Removing the OEM PCB (A06) (p. 262). (This step disconnects the W27 cable from
the OEM PCB.)
4. Remove the NIBP/CO2 module as described in Removing the NIBP (A21)/CO2 (A23) Modules (p. 288).
5. Disconnect the OEM PCB/NIBP module cable (W27) from the A21 NIBP PCB at J2.
Installing the OEM PCB/NIBP Module Cable (W27)
Refer to Figure 8.117 on p. 348.
To install the OEM PCB/NIBP module cable (3012181-00):
1. Connect the OEM PCB/NIBP module cable to the A21 NIBP PCB at J2.
2. Install the NIBP/CO2 module as described in Installing the NIBP (A21)/CO2 (A23) Modules (p. 292).
3. Install the OEM PCB (A06) as described in Installing the OEM PCB (A06) (p. 265).
4. Install the system/therapy PCB assembly as described in Installing the System (A01)/Therapy (A04) PCB Assembly (p. 239).
5. Reassemble the case as described in Reassembling the Case (p. 184).
