Chapter F: PARTS REPL
ACEMENT AND REPAIR
2 R
EMOVING C-ARM AND UPP
ER ARM COVERS
Technical manual
Planmeca ProOne
121
2.3 Removing the
tube head covers
Loosen the screws on the top and
bottom of the
tube head covers
using a 2.5 mm Allen
key. First loosen the tw
o top scr
ews and then the bottom screw.
Do not remove the
screws.
Tube head
cover
Top screw
Top screw
Bottom scre
w
122
124
