Technical manual Planmeca ProOne 75
Chapter C: ERROR MESSAGES
The X-ray unit incorporates a self-checking feature that monitors the operation of the unit.
• If the system detects an operating error, a help message (e.g. H03-001, blue line at
top) will appear on the control panel.
• If the system detects a technical fault, an error message (e.g. E02-004, red line at top)
will appear on the control panel.
The X-ray unit will not accept any commands until the message is cleared from the
display. Touch the green check mark button to clear the message.
The help and error messages are divided into the following groups:
The following lists show, in numerical order, all the error messages that can appear on the
control panel.
Refer to the X-ray unit’s User’s Manual for a complete list of the help messages.
02-XXX Motorized motion related
03-XXX X-ray generator related
04-XXX Communication related
05-XXX Power supply related
06-XXX System related
07-XXX Calibration related
