2 CALIBRATING DYNAMIC EXPOSURE CONTROL (DEC) Chapter E: CALIBRATIONS
112 Planmeca ProOne Technical manual
2 CALIBRATING DYNAMIC EXPOSURE CONTROL
(DEC)
NOTE
Dynamic Exposure Control (DEC) is an optional feature that requires a separate DEC
licence. Refer to section 3.1 "Program: Program licences (P2100)" on page 44 for
information on how to activate a DEC licence.
NOTE
Ensure that the X-ray beam is correctly aligned and the sensor calibrated before you start
DEC calibration. Check the position of the X-ray beam by taking a beam check exposure
with adult collimation as described in section 1.10 "Step 7: Taking beam check exposure"
on page 111. Refer to section 1 "ADJUSTING AND CALIBRATING X-RAY BEAM" on page
89 for information on how to align the X-ray beam and calibrate the sensor.
NOTE
For DEC calibration you need a separate DEC calibration tool (part number 10017027).
You will also need the sensor calibration block (part number 10016995).
NOTE
DEC must be calibrated before the DEC function can be used.
Remove the tube head inner cover by first loosening the bottom screw and then detaching
the cover.
NOTE
Always switch the X-ray unit off before removing any covers.
Switch the X-ray unit back on.
Bottom screw
Tube head
inner cover
