3 COLUMN PARTS REPLACEMENT Chapter F: PARTS REPLACEMENT AND REPAIR
130 Planmeca ProOne Technical manual
Rotate the lower steel cable pulley until the disc hole is positioned directly over the spindle
shaft.
Loosen the locking screw that holds the spindle shaft in place.
Lower steel cable pulley
Spindle shaft
