Chapter F: PARTS REPLACEMENT AND REPAIR 3 COLUMN PARTS REPLACEMENT
Technical manual Planmeca ProOne 145
Unscrew two slide fixture attachment screws using a 3 mm Allen key.
Remove the slide fixture, slide bar and nut bar.
