7 USER’S STATEMENT Chapter A: GENERAL & TECHNICAL DATA
20 Planmeca ProOne Technical manual
Reference axis to which the target angle and the focal spot
characteristics of the tube head assembly refer
Target angle with respect to the reference axis
12.5°
Dimensions of the tube head assembly
(WxHxD) 175 mm x 345 mm x 105 mm
Weight of the tube head assembly
7.4 kg
Values of loading factors concerning leakage radiation
70 kV, 7 mA
Tolerances of the focal spot on the reference axis
X= ±0.5 mm (sideways)
Y= ±0.5 mm (in depth)
Z= ±0.5 mm (in height)
