4 TECHNICAL SETTINGS Chapter B: SETTINGS
66 Planmeca ProOne Technical manual
• Beam profile (T3450)
Beam profile is an additional tool for monitoring the beam position. It can be used in
parallel with the beam check exposure described in section 1.10 "Step 7: Taking
beam check exposure" on page 111. Beam profile measures the signal level received
by the sensor within two cross sections taken from the upper and the lower zone of
the beam.
Enter the
Beam profile
menu by touching the respective field on the display.
