1 ERROR MESSAGES Chapter C: ERROR MESSAGES
82 Planmeca ProOne Technical manual
E05-014 Rotation & collimator
(PSU)
Voltage out of limits Voltage of positioning sensors (rotation and
collimator motor) is out of limits (4.7-5.3 V).
Check the voltage between J8-1 and J8-3
(rotation) and between J7-2 and J7-3
(collimator) on the PSU PCB.
E05-015 Generator (PSU) Low voltage Mid-circuit voltage of the X-ray generator is
too low.
Replace the PSU assembly. Then perform
the filament definition again.
E05-016 30 V (CPU) CPU voltage is too low (< 21 V).
Check the voltage between TP7 and TP8
(GND) on the CPU PCB.
E05-017 Power supply to linear motor is too low
(motor power < 23 V).
Check the cabling by disconnecting/
reconnecting cables for linear motor (J3). If
necessary, replace the CPU PCB.
Code Explanation Comments
