Crankshaft, Main Bearings, and Flywheel
02
040
4
RG,RG34710,151 –19–30SEP97–1/2
Remove Crankshaft Vibration Damper and
Pulley
RG8175A –UN–05DEC97
Removing Damper Retaining Ring
RG8176 –UN–05DEC97
Installing JDG973-1 Hub
A—Large Washer
B—JDG973-1 Remover/Installer Hub
CAUTION: Damper and pulley are very heavy.
Plan proper handling procedures to avoid
injury. ALWAYS use an assistant when
removing and installing pulley.
IMPORTANT: DO NOT immerse damper assembly in
petroleum products (such as gasoline,
oil, solvent, etc.). Doing so can damage
the rubber portion of the assembly.
Never apply thrust on outer ring of
damper. The damper is sensitive to
impact damage from being dropped or
struck with a hammer.
NOTE: Remove front bolt-on pulley from vibration damper
assembly for access to front nose of crankshaft, if
equipped.
1. Remove six cap screws and large washer (A) from
front nose of crankshaft.
2. Install JDG973-1 Remover/Installer Hub (B) onto nose
of crankshaft with two hex socket head cap screws
provided in kit. Tighten cap screws until they bottom on
hub.
3. Lubricate threads of remover/installer with
multi-purpose grease.
Continued on next page
CTM100 (06APR04)
02-040-4
P
OWER
T
ECH
10.5 L & 12.5 L Diesel Engines
040604
PN=200
