Air Intake and Exhaust System
02
080
15
RG,RG34710,246 –19–30SEP97–1/1
Prelube Turbocharger
RG8543 –UN–20MAY98
Prelubing Turbocharger Bearings
IMPORTANT: DO NOT spin the rotor assembly with
compressed air. Damage to bearings
can occur when using compressed air.
Fill oil inlet or drain port with clean engine oil and spin
rotating assembly (by hand) to properly lubricate bearings.
If turbocharger is to be stored for an extended period of
time, lubricate internally and install protective covers on all
openings.
CTM100 (06APR04)
02-080-15
P
OWER
T
ECH
10.5 L & 12.5 L Diesel Engines
040604
PN=315
