Crankshaft, Main Bearings, and Flywheel
02
040
40
RG,RG34710,180 –19–13AUG99–2/4
RG8424 –UN–09DEC97
Seating Front Seal on Damper
RG8535 –UN–20MAY98
Front Seal Installed on Damper
A—JDG974-1 Seal Installer
4. Install JDG974-1 Seal Installer (A) with friction washer
and nut.
5. Tighten nut until installer bottoms on rear face of
damper.
6. Remove tools and clean any sealant from tools.
Continued on next page
CTM100 (06APR04)
02-040-40
P
OWER
T
ECH
10.5 L & 12.5 L Diesel Engines
040604
PN=236
