Repair and General OEM Specifications
06
200
8
OUO1004,0000BC6 –19–19SEP02–4/4
Item Measurement Specification
Step 2—All Cap Screws (Nos. 1— Initial Torque 163 N•m (120 lb-ft)
26)
Step 3—Wait 5 Minutes and Verify Torque 163 N•m (120 lb-ft)
All Cap Screws (Nos. 1—26)
Step 4—All Cap Screws (Nos. 1— Initial Torque-Turn 90°
26)
Step 5—All Cap Screws (Nos. 1— Final Torque-Turn 90°
26)
5
Rocker Arm Shaft Hold-Down Clamp Initial Torque 30 N•m (22 lb-ft)
Cap Screws (All Engines)
Rocker Arm Shaft Hold-Down Clamp Final Torque-Turn 60°±5°
Cap Screws (Dual Rail Fuel System)
Rocker Arm Shaft Hold-Down Clamp Final Torque-Turn 90° +10° —0°
Cap Screws (Single Rail Fuel
System)
Unit Injector Wiring Harness Torque 25 N•m (18 lb-ft)
Bracket-to-Rear of Head
Unit Injector Wiring Harness Torque 3.0 N•m (27 lb-in.)
Solenoid Wire Retaining Nut
6
Unit Injector Harness Clips-to-Rocker Torque 35 N•m (26 lb-ft)
Arm Shaft Clamps
5
Total torque-turn for steps 4 and 5 is 180
°
.
6
Apply LOCTITE 222 (TY24311) Thread Lock and Sealer (Low Strength)
to nut only.
CTM100 (06APR04)
06-200-8
