ENGINE DISASSEMBLY SEQUENCE—CONTINUED
Procedure Reference
Remove cylinder block front plate. See REMOVE AND INSTALL CYLINDER BLOCK FRONT PLATE in
Group 030.
Perform wear checks on connecting rod bearing surfaces using See REMOVE PISTONS AND CONNECTING RODS in Group 030.
PLASTIGAGE

. Remove piston and connecting rod assemblies.
Check crankshaft end play. See CHECK CRANKSHAFT END PLAY in Group 040.
Remove main bearing caps with bearings. Perform wear checks on See REMOVE CRANKSHAFT MAIN BEARINGS in Group 040.
main bearing surfaces with PLASTIGAGE

. See CHECK MAIN BEARING-TO-JOURNAL OIL CLEARANCE in
Group 040.
Remove crankshaft. See REMOVE CRANKSHAFT in Group 040.
Remove cylinder block plugs and serial number plate if block is to be See COMPLETE DISASSEMBLY OF CYLINDER BLOCK in Group
put in a hot tank. 030.
Inspect and repair individual components. See appropriate repair groups.
PLASTIGAGE is a registered trademark of the DANA Corp.
