Manual No. 7018081-02, Rel. Jun. 1999
REMOVAL and INSTALLATION
© Copyright Isringhausen 1999
MODEL 6800/338 BUS
MODEL 6800/338 PREMIUM LX
Distribution valve
Set up
• Seat cushion must be removed
from seat (see Cushion seat
pan)
Removal
• Mark and remove air lines from
valve
• Remove valve fastener and
remove valve
Installation
• Fasten valve to frame with screw
• Connect air lines
Headrest
Set up
• Vehicle must be in a safe parked
position or seat removed from
vehicle
Removal
• Pull headrest to upper locking
position
• Press foam, as shown, to
release locking clip from detent
on headrest and pull up
Installation
• Guide headrest bars into position
• Press down to engage locking
clip
PRESS
HERE
