Page 1 of 3 02371-02 Date: May 21, 2001
SERVICE PARTS LIST
ISRI P/N: 02371-02 Description: Seat Frame-515-LH-AL/MV(RH)
ISRI Illus. No.: E-059
Customer: Prevost Car Customer P/N: 861099
Specification: LH controls, double swivel bolt, controls – black w/symbol,
Air lumbar/Manual valve-RH (IPS 5)
ILLUS
NO.
DESCRIPTION ISRI P/N CUSTOMER P/N
E1 Side Plate Kit 95733-03 860487
E3 Valve Kit – Air Lumbar/MV 917471-04 861096
E4 Valve Asm – Air Lumbar/MV * 35270-01
E5 Torsion Bar Kit 95739-01 861091
E7 Spring Kit – Height/Slope 95619-04 860755
E8 Bushing Kit – Height/Slope 95773-01 860753
E9 Bushing / Hdw Kit – H/S 95847-01 860754
E13 Tooth Plate Kit 914209-05
E14 Swivel Bolt / Clip Kit 914204-02 860757
E50 Cover – Seat Frame – Rear See E1
E51 Hose–Lumbar Upper-Rubber See E4
E52 Cover – Side Plate – RH See E1
E54 Handle – H/S – Front * 47270-02
E55 Cap – Side Plate See E1
E56 Handle – Backrest * 43537-02
E57 Cover – Side Plate – LH See E1
E58 Hose-Lumbar Supply-PU3 See E4
E59 Cap – Torsion Bar See E5
E60 Bar – Torsion See E5
E61 Lock – Torsion Bar See E5
E62 Pad – Felt * 42258
E63 Seat Frame w/o Covers 917673D
E65 Screw – Hose Guide See E3
E66 Hose Guide See E3
E67 Hose-Lumbar Lower-Rubber See E4
E70 Nut – Tee See E3
E73 Bushing See E8 or E9
E74 Link-Pivot-H/S-Opp Control See E63
E75 Ring – Retaining See E14
E76 Bolt – Swivel See E14
* PART OF KIT
To Next Page
