Page 2 of 3 02371-02 Date: May 21, 2001
SERVICE PARTS LIST
ISRI P/N: 02371-02 Description: Seat Frame-515-LH-AL/MV(RH)
ISRI Illus. No.: E-059
Customer: Prevost Car Customer P/N: 861099
Specification: LH controls, double swivel bolt, controls – black w/symbol,
Air lumbar/Manual valve-RH (IPS 5)
ILLUS
NO.
DESCRIPTION ISRI P/N CUSTOMER P/N
E77 Bolt – Shoulder – M8 See E9
E78 Bushing See E8 or E9
E79 Link-Pivot-H/S-Control See E63
E80 Lever – Backrest Adjust 41509D
E81 Ring – Retaining See E1
E82 Spring – Tension – Backrest 41552D 860751
E83 Plate – Latch – H/S – Rear 35865J
E84 Pin – Pivot – Latch 40647N
E85 Ring – Retaining 60020
E86 Guide – H/S 42962
E88 Spring – Tension See E7
E89 Lever – H/S – Front 43012D 860588
E90 Spring – Tension See E7
E91 Spring – Tension See E7
E92 Plate – Latch – H/S – Front 47275D 860756
E93 Ring – Retaining 60020
E94 Nut – Hex – Crimp Lock – M8 See E9
E95 Linkage – H/S – Rear – DS See E63
E96 Ring – Retaining 60047
E97 Link See E63
E98 Plate – Tooth – Seat Frame See E13
E99 Ring – Retaining See E13
E100 Ring – Retaining 60020
E102 Bushing See E8
E103 Ring – Retaining 60020
E104 Clip – U 60186
E105 Linkage – H/S – Front – DS See E63
E138 Hose-PU3 (MV/Air Spring) See E3
E139 Housing – AL/MV * 24111-02
E140 Screw-Mtg-AL/MV Housing See E3
E141 Cover – Rocker – AL – Lower * 45480-24 861094
* PART OF KIT
