Page 3 of 3 02371-02 Date: May 21, 2001
SERVICE PARTS LIST
ISRI P/N: 02371-02 Description: Seat Frame-515-LH-AL/MV(RH)
ISRI Illus. No.: E-059
Customer: Prevost Car Customer P/N: 861099
Specification: LH controls, double swivel bolt, controls – black w/symbol,
Air lumbar/Manual valve-RH (IPS 5)
ILLUS
NO.
DESCRIPTION ISRI P/N CUSTOMER P/N
E142 Washer – Flat – A8.4 See E3
E143 Sleeve – Push On – PU4 * 46097-02
E144 Sleeve – Push On – PU3 * 44713-02
E145 Ring – Retaining 60045
E147 Hose-PU3 (AL Supply) See E3
E149 Valve – AL/MV (IPS5) See E4
E150 Cover – Rocker – AL – Upper * 45480-23 861093
E152 Cover – Rocker – MV (+/-) * 46680-02 861097
E156 Plastic Tie See E3
E179 Connector - “Y” - PU4 * 44712
E181 Connector–Inline–PU4/PU3 * 44436
E182 Connector-Inline-PU3/PU3 * 46708
E183 Hose-PU4 (Y/Valve Supply) See E3
E184 Hose-PU4 (Supply/Y) See E3
E185 Tag – “P” (Supply Hose) See E3
* PART OF KIT
