Section 07: TRANSMISSION
PA1562
28
ON MESSAGES CENTER
DISPLAY (MCD)
SAE-J1587 Codes
ON SHIFT SELECTOR
DISPLAY
ISO CODES WITH
TESTMAN TOOL
DESCRIPTION
34,3 22 82 Short circuit to positive at output stage to small disengagement clutch valve
34,3 22 83 Short circuit to positive at output stage to small engagement clutch valve
34,3 22 84 Short circuit to positive at output stage to large disengagement clutch valve
34,3 22 85 Short circuit to positive at output stage to large engagement clutch valve
35,5 23 41 Interruption at output stage to Y9 (Valve Range)
35,3 23 73 Short circuit to positive at output stage to Y9 (Valve range)
35,6 23 9 Short circuit to ground at output stage to Y9 (Valve Range)
36,5 24 40 Interruption at output stage to Y8 (Valve Range)
36,3 24 72 Short circuit to positive at output stage to Y8 (Valve range)
36,6 24 8 Short circuit to ground at output stage to Y8 (Valve Range)
37,6 25 2 Short circuit to ground at output stage to Y2 (Valve Splitter)
37,5 25 34 Interruption at output stage to Y2 (Valve Splitter)
37,3 25 66 Short circuit to positive at output stage to Y2 (Valve Splitter)
38,6 26 3 Short circuit to ground at output stage to Y3 (Valve Splitter)
38,5 26 35 Interruption at output stage to Y3 (Valve Splitter)
38,3 26 67 Short circuit to positive at output stage to Y3 (Valve Splitter)
39,5 27 36 Interruption at output stage to Y4 (Valve Select)
39,6 27 4 Short circuit to ground at output stage to Y4 (Valve Select)
39,3 27 68 Short circuit to positive at output stage to Y4 (Valve Select)
40,5 28 38 Interruption at output stage to Y6 (Valve Shift)
40,6 28 6 Short circuit to ground at output stage to Y6 (Valve Shift)
40,3 28 70 Short circuit to positive at output stage to Y6 (Valve Shift)
43,2 2B 175 Error on ”Ignition lock” signal (terminal 15)
48,3 30 129 No shift sensor signal (Short circuit to positive)
48,6 30 130 No shift sensor signal (Short circuit to ground)
48,5 30 131 No shift sensor signal (Interruption)
48,13 30 132 Self adjustment error of shift sensor
48,7 30 157 Selector sensor signal leaves position during driving
48,7 30 158 Engage sensor signal leaves engaged position during driving
50,5 32 37 Interruption at output stage to Y5 (Valve Select)
50,6 32 5 Short circuit to ground at output stage to Y5 (Valve Select)
50,3 32 69 Short circuit to positive at output stage to Y5 (Valve Select)
51,5 33 39 Interruption at output stage to Y7 (Valve Shift)
51,6 33 7 Short circuit to ground at output stage to Y7 (Valve Shift)
