Section 07: TRANSMISSION
PA1562
29
ON MESSAGES CENTER
DISPLAY (MCD)
SAE-J1587 Codes
ON SHIFT SELECTOR
DISPLAY
ISO CODES WITH
TESTMAN TOOL
DESCRIPTION
51,3 33 71 Short circuit to positive at output stage to Y7 (Valve Shift)
54,6 36 17 Short circuit to ground at output stage to Y1 (inertia brake valve)
54,5 36 49 Interruption at output stage to Y1 (inertia brake valve)
54,3 36 81 Short circuit to positive at output stage to Y1 (inertia brake valve)
55,7 37 114 Clutch engaged unintentionally at standstill, gear engaged
55,7 37 118 Clutch does not disengage
55,7 37 119 Clutch does not engage / does not transmit engine torque
56,7 38 145 Range change group (GP) disengagement error
56,7 38 146 Changeover error during range change group (GP) shifting
56,7 38 147 Range change group (GP) does not engage
57,2 39 108 Error in shift lever
57,14 39 110 ZF CAN timeout (can also means shift lever error through ZMP06400.hex)
58,7 3A 154 Main transmission gear does not disengage
58,7 3A 155 Main transmission gear does not engage
58,7 3A 156 Wrong gear shifting
59,7 3B 151 Selector cylinder does not disengage
59,7 3B 152 Change over error during gate selection procedure
59,7 3B 153 Selector cylinder does not engage
60,3 3C 133 No gate select sensor signal (Short circuit to positive)
60,6 3C 134 No gate select sensor signal (Short circuit to ground)
60,5 3C 135 No gate select sensor signal (Interruption)
60,13 3C 136 Gate select sensor self adjustment error
61,7 3D 148 Splitter (GV) does not disengage
61,7 3D 149 Change over error during splitter shifting
61,7 3D 150 Splitter (GV) does not engage
63,14 3F 100 Error on output speed signal 2
106,0 6A 125 Error on pressure reduction valve
106,14 6A 126 Error on pressure sensor signal
150,14 96 59 Acknowledge fault of PTO 1
150,14 96 60 Acknowledge fault of PTO 2
150,7 96 61 Disengagement fault of PTO 1
150,7 96 62 Disengagement fault of PTO 2
150,7 96 63 Engagement fault of PTO1
150,7 96 64 Engagement fault of PTO2
