Page No.19

NDS2 issue A

Spicer SpecialityAxle Division - Technical Publications

PART N

DESCRIPTION TIGHTENING TORQUE

1 Wheel nut M18 x 1.5 ----------------------------------------------- 235 - 260 lbs.ft 318 - 352NM

Wheel nut M20 x 1.5 ----------------------------------------------- 285 - 315 lbs.ft 386 - 427NM

Wheel nut M22 x 1.5 ----------------------------------------------- 475 - 525 lbs.ft 644 - 712NM

7 Hub flange retaining bolt M14 x 1.5---------------------------- 174 - 192 lbs.ft 236 - 260NM

8 Brake drum retaining screw -------------------------------------- 26 - 32 lbs.ft 35 - 43NM

Fig.No.23
