PREVOST X3-45 Multiplex User Manual

Section 12: BRAKE AND AIR SYSTEM
PA1562
30
AB-Type Copper Piping: Hand tighten nut
(Fig. 51). From that point, tighten with a wrench
the number of turns indicated in the following
chart.
Piping diameter
(inches)
Number of additional turns
required following hand
tightening
1/4, 3/8, 1/2 2
5/8, 3/4 3
FIGURE 51: HOSE FITTING 12056
Pipe Tightening: All connections must be hand
tightened. From that point, tighten a minimum of
2 ½ additional turns.
NOTE
Use Locktite (Prévost number 680098) pipe
sealant to seal pipe thread.

PREVOST X3-45 Multiplex Specifications

General

Length	45 ft
Width	102 in
Engine	Volvo D13
Horsepower	500 hp
GVWR	54, 000 lbs
Height	146 in
Sleeping Capacity	Varies based on floor plan
Water Capacity	Varies based on floor plan
