PREVOST X3-45 Multiplex User Manual

Section 1
Introduction
Maintenance Manual MM-0204 Copyright 2002
Issued 08-02 ArvinMeritor, Inc. Page 3
Visual Inspection
A visual check of the compressor can detect minor problems (see legend for examples of these problems).
This check should be part of the vehicle preventive maintenance program. Figure 1.5 .
Figure 1.5
1 Check water ports for leakage.
2 Check air inlet and discharge ports for leakage.
3 Check around end cover for oil leakage.
4 Check flanges for cracks or breaks.
4000267c
2
1
3
4

PREVOST X3-45 Multiplex Specifications

General

Length	45 ft
Width	102 in
Engine	Volvo D13
Horsepower	500 hp
GVWR	54, 000 lbs
Height	146 in
Sleeping Capacity	Varies based on floor plan
Water Capacity	Varies based on floor plan
