PREVOST X3-45 Multiplex - Page 708

2
4
TUBELESS WHEELS (round hand holes) ENGLISH UNITS — continued
Item
no.
Wheel
description
Maximum
wheel load
1
in lbs.
Approx.
Wheel wt.
lbs.
Outset
inches
3
Inset
inch-
es
Maxi-
mum
ination
PSI—
cold
Valve
stem***
(Alcoa Part
No.)
Part
number
2
Available
nishes
4
Stabi-
lizer
Front outer cap
nuts
Rear
inner
cap nuts
Al/Al
Rear in-
ner cap
nuts
Al/Stl
Rear outer cap
nuts
10-hole, hub piloted mounting—285.75mm bolt circle, 220.1mm hub bore, 26.75mm bolt hole diameter (use two-piece ange nuts)
Lug nut covers: 181 Hub covers: Front - 076018 or 076085‡ Rear - 077018 or 077085‡
One-Piece hub cover system: Front - 086100S, Rear - 087100S
14
22.5x7.50-
15°DC
7300 53 6.28 5.44 120
TR555D
(005554)
873600
0, 1, 2, 0DB**,
1DB**, 2DB**
2225 39874 - - 39874
15
22.5x8.25-
15°DC
7400 47 6.66 5.81 130
TR554D
(005544)
883640
0, 1, 2, 3,
0DB,1DB, 2DB,
3DB, 0DF, 1DF,
2DF, 0DD,
1DD, 2DD
8864 39874 - - 39874
§16
22.5x8.25-
15°DC
8000 55 6.66 5.69 130
TR553C
(005533)
885600
0, 1, 2, 0DF,
1DF, 2DF
- 39874 - - 39874
17
22.5x9.00-
15°DC
9000 59 6.94 6.04 130
TR554D
(005544)
893640
0, 1, 2, 3, 0DB,
1DB, 2DB, 3DB,
0DF, 1DF, 2DF,
3DF,
0DD, 1DD,
2DD, 3DD
8964 39874 - - 39874
18
22.5x9.00-
15°DC
10,000 53 — 3.12 130
TR555E
(005555)
893630
0, 1, 0DB**,
1DB
- 39874 - - 39874
19
22.5x10.50-
15°DC
10,500 68 6.61 5.5 130 TR553 (005530) 803600 1, 1DB** - 39874 - - -
20
22.5x12.25-
15°DC
12,300 63
.56
Revers-
ible
– 130
TR553E
(005535)
823600 0, 2 - 39874 - 39874
*21
22.5x12.25-
15°DC
11,400 66 3.88 2.75 130
TR553E outset
(005535)
TR555E inset
(005555)
823650
0, 1, 2, 9, 0DB,
1DB, 2DB,
9DB
0DF, 1DF, 2DF,
9DF
- 39874 - - 39874
22
22.5x12.25-
15°DC
11,000 68 5.8 4.68 130 TR552 (005520) 823640
0, 1, 0DB, 1DB,
0DF, 1DF
- 39874 - - 39874
*23
22.5x13.00-
15ºDC
12,300 70 3.5 2.38 130
TR553E outset
(005535)
TR555E inset
(005555)
833650 0,1,2,9 - 39874 - - 39874
24
22.5x13.00-
15°DC
11,000 74 6.42 5.3 130 TR552 (005520) 833640 0, 1 - 39874 - - 39874
††25
22.5x14.00-
15°DC
12,800 68 2.0 — 130
TR553E outset
(005535)
841600 0, 2, 0DB, 2DB - 39874 - - 39874
††26
22.5x14.00-
15°DC
12,800 71 1.13 0 130
TR555E outset
(005555)
TR553E inset
(005535)
841610
0, 1 , 2, 9, 0DB,
1DB, 2DB,
9DB
- 39874 - - 39874
27
24.5x8.25-
15°DC
7400 56 6.6 5.73 130
TR555D
(005554)
983640
0, 1, 2, 3, 0DB,
1DB, 2DB,
3DB, 0DF, 1DF,
2DF, 3DF
8864 39874 - - 39874
§28
24.5x8.25-
15°DC
8000 65 6.6 5.63 130
TR555D
(005554)
985600
0, 1, 2, 0DF,
1DF, 2DF
- 39874 - - 39874
10-hole, hub piloted bus mounting—11.25 in. bolt circle, 8.670 in. hub bore, 1.219 in. bolt hole diameter (use two-piece ange nuts)
Lug nut cover: 182 Hub covers: N/A
29
22.5x8.25-
15°DC
7300 53 6.66 5.82 120
TR555D
(005554)
883610
0, 3, 0DB, 3DB,
0DF, 3DF, 0DD,
3DD
- - - - -
30
24.5x8.25-
15°DC
7300 62 6.6 5.77 120
TR555D
(005554)
983610
0**, 3**,
0DB**, 3DB**
2245 - - - -
Specications are subject to change without notice. To request a copy of the current Alcoa Specications Data brochure for aluminum
wheels for trucks, trailers and buses, call toll-free 800-242-9898. To view online, go to www.alcoawheels.com. The Spec Data brochure con-
tains current part number availability and complete specications such as wheel dimensions, load rating, wheel weight, outset and inset,
ination pressure and accessory part numbers.
Alcoa provides training, live or on video, on proper wheel installation and maintenance practices free of charge. Contact Alcoa Wheel and
Forged Products at 800-242-9898.
Note: Dura-Bright® wheels produced after November 2002 have Alcoa wheel part numbers ending with “DB” (earlier wheels have part
numbers ending in a 4 or 7). Not all Alcoa wheels are available with the Dura-Bright®surface treatment.
