QL-30/60 User Guide 103
13
Test Functions
Overview
The Test menu contains test functions providing information on:
• the most important configuration parameters
• the fonts available in the printer
• important hardware components and connected peripheral devices
• the print image quality and state of the thermal printhead
• available WLAN networks.
Status Print
The Status print function prints a test image containing information on the configuration and
status of the printer. The printout occurs using the heat level and print speed specified in the
Setup > Printing menu.
Note: The printout occurs without taking the label gaps into consideration. This is why
continuous media is most suitable for this purpose.
1) Insert printable medium (labels, continuous media) which extends across the entire printing
width.
2) If the printout is to occur using thermal transfer printing, insert transfer ribbon with the
maximum width.
3) Start menu.
4) Select Test > Status print.
